ON4-03VW Advanced Natural Convection Oven (Window-door, 26L, 120V, 60Hz)

Availability:

Only 1 left in stock


Uniform temperature distribution through airflow optimized for uniform heat transfer (within ±3.6 ℃ at 100℃) and advanced functions

$2,608.00

Only 1 left in stock

Intuitive Large Touch Controller

  • Intuitive interface with 5-inch display.
  • Events and alerts in a single view with real-time graph.
  • Three frequent temperatures automatically suggested.
  • ‘Wait on / Wait off’ timer function.

Large intuitive display

Graphs for real-time process monitoring



Convenient Structural Functions

  • Designed with a depth of less than 750 mm, making it easy and stable on a lab table.
  • Uniform and stable temperature distribution with multi-path airflow improves reliability of experiment data.

Depth of less than 750 mm allows stable positioning on lab table

Uniform temperature control with multi-path airflow



Supervise Equipment with Real-time Monitoring

  • Monitor the temperature on BMS (Building Management System) for quick responses to abnormalities. (option).
  • Monitor and control anywhere, anytime with LC GreenBox (Mobile Monitoring System, option).

Timely responses via BMS-connected monitoring (BMS port: option)

Real-time monitoring via mobile devices (LC GreenBox: option)



Convenient Experiment and Data Checking

  • Support RS-232/USB port and software making easy operation and data management from PC.
  • Test data are automatically stored and easily exported via USB; easy to edit data (in CSV format).
  • Logs 36 recent events, including errors, opened door, etc.
  • Integrated with 21 CFR Part 11 compliant LC DataKeeper, suitable for GMP audits (option).

Data storage using USB ports

Store recent 36 events



Reliable Temperature Control Performance

  • Wide temperature range of up to 250℃.
  • Temperature accuracy for wide range by 3-point calibration.
  • Ramp Control™, function that controls the rate of temperature rise by setting ramping rate(℃/min) per experiment.
  • Uniform temperature distribution through airflow optimized for uniform heat transfer (within ±3.6 ℃ at 100℃).

Accurate temperature control with 3-point calibration

Ramp Control™ per experiment condition

SKU: AAH112106U Category:
Model Solid Door (without window) ON4-03V
Window door ON4-03VW
Chamber volume (L / cu ft) 26 / 0.92
Temperature Range (℃ / ℉) Amb. +15 to 250
/ Amb. +59 to 482
Fluctuation at 100℃ (±℃ / ℉) 0.4 / 0.72
Variation at 100℃ (±℃ / ℉) 2.8 / 5.04
Heating time to 100℃ (min.) 1) 25
Recovery time at 100℃ (min.) 17
Control panel 5 inch TFT Color LCD
Communication interface USB-B, RS-232
Function Recently event record 36 ea
Recommended temperature Suggest three frequently used temperature
Graph Available viewing stored and real-time graphs
Data storage Save your experiment data (in CSV format)
Temp. ramping rate (℃/min. | ℉/min) 0 to 2.2 | 0 to 3.96
Dimension
(W×D×H)
Interior (W x D x H, mm / inch) 273 x 270 x 350
/ 10.75 x 10.63 x 13.78
Exterior (W x D x H, mm / inch) 478 x 527 x 604
/ 18.8 x 20.75 x 23.78
Net weight (Kg / lbs) 33 / 72.8
Shelves Quantity of shelves (standard/max.) 2 / 4
Max. Load per shelf (Kg / lbs) 20 / 44.09
Number of air change per hour at 100℃ 16
Electrical requirements (120V, 60Hz, A) 6
Cat. No.
Solid Door (without window) AAH111106U
Window door AAH112106U

Heating time is defined as the time taken to reach 98% of the set temperature.

※ Technical data according to DIN 12880
